Product Application
It is mainly used for screening in different industries such as pharmaceutical, food, chemical and plastic fields. Normally it is used together with granulation auxiliary equipments.
Product Features
1. The straight-line vibration sieve is well designed and easy to operate.
2. The sieve is easy to change and clean.
3. The impurities and coarse materials will be automatically discharged.
4. The parts which may touch raw material are all made by stainless steel so as to guarantee the purity.
5. Straight-line vibration sieve is easy to maintain and has less malfunctions.
6. Besides the standard sieves, it also can be customized according to customers’ requirements.
Operation principle:
It obtains vibrating force from centrifugal force caused by vibration motor. The vibrating force lets sieve and material perform vertical reciprocating motion. The materials will be separated into three fineness levels according to the different pore-size of two sieve layers so as to satisfy the production requirements.
Technical Parameters
| Model | Power
(kw) |
Size(mm) | Sieve pore of diameter | Output
(kg/h) |
Remaks |
| ZS350 | 0.2 | 1150×450×550 | top layer 6mm ,under layer 2mm | 300 | Use Stainless steel when touch raw meterial |
| ZS500 | 0.2×2 | 1400×600×650 | top layer6mm ,under layer2mm | 500 | |
| ZS800 | 0.2×2 | 1700×700×700 | top layer6mm ,under layer2mm | 800 |
